技術指標 Electrical specifications
頻率范圍 Frequency Range(MHz)	880-960; 1.71-2.7GHz/3.3-5 GHz
極化方式 Polarization	垂直/水平
增益 Gain(dBi)	6-8
前后比 Front To Back Ratio (dB)
半功率角 Half-power Beam Width(°)	H: 60° E: 60°
阻抗 Impedance(Ω)	Ω50
駐波比 V.S.W.R	≤1.5
功率容量 Max. Input Power (W)	100
雷電保護 Lightning Protection	直接接地

機械指標 Mechanical specifications
接頭 Connector	自定
長度最大直徑 Dimension (HW*D)/Max. Diameter (mm)	28518065
天線重量 Weight(Kg)
抗風能力 Rated Wind Velocity(m/s)	60m/s
工作溫度 Operating Temperature(℃)	-40 ~ +70
工作濕度 Humidity
安裝方式 Installation	壁掛
天線罩材料 Radome Material	ABS

精華全新研發5G系列天線，自帶雙輸入/輸入插頭，頻率覆蓋范圍極廣，能夠完美配合現有4G以及未來5G室內信號覆蓋的應用。我們的產品具有高增益，高效率，質量輕，防水防曬等特點，適合戶外或者室內使用。

With two ports for both signal input and output, our 5G Series antennas are multitask, lightweight, and they provide high gains and constant performance across a broad frequency range from 880MHz to 5GHz, with your choice of pole/wall installation. The antenna is suitable for outdoor or indoor use.

Broad Response --- With 1070/2700MHz bandwidth, this antenna provides ideal performance in single or multi-frequency system.

High Gain --- 6-8dBi gain provides optimized pattern coverage for either indoor or outdoor applications.

Dual band MIMO --- With dual ports working together, users could enjoy fast network from newest 5G technology while the 3G/4G signals unaffected.

Weather Resistant --- DC ground for lightning protection and IP67 waterproof level for our products to work under extreme weather conditions.

Also In Package ---Product test report and installation manual will be provided to each set of Jinghua antenna.

Customization --- These antennas can be customized for different frequencies and gains.
